As an integrated diesel engine manufacturer, Doosan Engine is specialized in diesel engines for large vessels, as well as the construction of internal combustion power plants that use diesel engines. Doosan Engine has the second largest global market share with an annual production capacity of 9 million bhp. With 20 years of experience, Doosan Engine recorded an annual order backlog of more than $ 1 billion in the last three consecutive years.
Type | Output Power |
Cuurrent (A) | Engine model | Cylinder |
Bore*Stroke (mm) |
FuelCon. (L) |
Dis. g/kw.h |
Dimension(mm ) L*W*H | Weight(kg) | Detail | |
KW | KVA | ||||||||||
JHD-50GF | 50 | 62.5 | 90 | DB58 | 6 | 102*118 | 5.785 | 215 | 2000*730*1150 | 900 | Click |
JHD-64GF | 64 | 80 | 115.2 | D1146 | 6 | 111*139 | 8.071 | 222 | 2200*800*1500 | 1100 | Click |
JHD-75GF | 75 | 93.7 | 135 | D1146 | 6 | 111*139 | 8.071 | 222 | 2200*800*1500 | 1100 | Click |
JHD-100GF | 100 | 125 | 180 | D1146T | 6 | 111*139 | 8.071 | 200 | 2300*800*1500 | 1500 | Click |
JHD-120GF | 120 | 150 | 216 | DP086TA | 6 | 111*139 | 8.1 | 201 | 2300*800*1500 | 1600 | Click |
JHD-132GF | 132 | 165 | 237.6 | DP086TA | 6 | 111*139 | 8.1 | 202 | 2300*800*1500 | 1600 | Click |
JHD-150GF | 150 | 136 | 270 | P086TI-1 | 6 | 111*139 | 8.071 | 207 | 2550*1000*1500 | 1750 | Click |
JHD-180GF | 180 | 225 | 324 | P086TI | 6 | 111*139 | 8.071 | 202 | 2600*1000*1500 | 1800 | Click |
JHD-200GF | 200 | 250 | 360 | DP086LA | 6 | 111*139 | 8.1 | 203 | 2700*1000*1500 | 1800 | Click |
JHD-220GF | 220 | 275 | 396 | P126TI | 6 | 123*155 | 11.051 | 205 | 2900*1050*1650 | 2400 | Click |
JHD-240GF | 240 | 300 | 432 | P126TI | 6 | 123*155 | 11.051 | 205 | 2900*1050*1650 | 2400 | Click |
JHD-260GF | 260 | 325 | 468 | P126TI-II | 6 | 123*155 | 11.051 | 202 | 3000*1050*1650 | 2600 | Click |
JHD-300GF | 300 | 375 | 540 | P158LE-1 | 8 | 128*142 | 14.618 | 232 | 3100*1400*1850 | 2700 | Click |
JHD-320GF | 320 | 400 | 576 | P158LE-1 | 8 | 128*142 | 14.618 | 232 | 3100*1400*1850 | 2700 | Click |
JHD-350GF | 350 | 437.5 | 630 | P158LE | 8 | 128*142 | 14.618 | 209 | 3100*1400*1850 | 2800 | Click |
JHD-400GF | 400 | 500 | 720 | P158LE-S | 8 | 128*142 | 14.618 | 210 | 3120*1400*1850 | 3000 | Click |
JHD-440GF | 440 | 550 | 792 | P180LE | 10 | 128*142 | 18.273 | 205 | 3300*1400*1850 | 3200 | Click |
JHD-500GF | 500 | 625 | 900 | P222LE-1 | 12 | 128*142 | 21.927 | 200 | 3400*1400*1850 | 3500 | Click |
JHD-550GF | 550 | 687.5 | 990 | P222LE-S | 12 | 128*142 | 21.927 | 207 | 3400*1400*1850 | 3700 | Click |
JHD-600GF | 600 | 750 | 1080 | P222LE-II | 12 | 128*142 | 21.927 | 210 | 3500*1400*1850 | 4000 | Click |
JHD-650GF | 650 | 812.5 | 1170 | P222FE-II | 12 | 128*142 | 25.42 | 207 | 3600*1400*1850 | 4500 | Click |
